Akron Brass 1" Swing-Out Valve (Body Only) w/Stainless Ball and R-1 Handle

Sale Sale
Original price $427.00
Original price $427.00 - Original price $427.00
Original price $427.00
Current price $370.55
$370.55 - $370.55
Current price $370.55
SKU 200056001

This is the Akron Brass 1" Swing-Out Valve (Body Only) w/Stainless Ball and R-1 Handle. It is a self-locking, heavy-duty valve with a stainless steel ball designed for the harsh realities of today's fire service when water contaminants challenge a valve's sealing capabilities. The R-1 handle attaches to a linkage for a push-pull operation at the pump panel. This version has rigid NPT female adapters on either side of the valve.

Features:

  • Single Valve Body with the R1 Actuator
  • 1" waterway
  • 107° handle travel
  • 316 stainless steel ball for longer valve life
  • High-quality brass body
  • Improve sealing & increased gating ability
  • Flow optimization reduces turbulence while in the gated position and requires lower operating forces
  • No lubrication or regular maintenance is required
  • Simple two-seated design (no O-rings to cut or lose during assembly or maintenance)
  • Wide range of available adapters
  • HydroMax TM technology: A patented ball geometry providing performance never seen before in swing-out valves
  • Designed and tested to exceed NFPA requirements
  • Cast, machined, and assembled in the USA
  • 10-Year Warranty from Akron Brass

Note: An R-1 actuator handle is included in this price. The Field Service Kit for this item is available here.
